Min-body JM-F Performance Characteristic:
  • This product has new, the contour practical and so on many patents, the contour is novel, overall health, environmental protection energy conservation.

  • This product execution country standard GB/T 14,466 and enterprise standard Q/WSS01-2004, is the domestic origination.

  • This product organism spot and the material contact part use the stainless steel material. Rack and electric motor steel and iron paint.

  • This product matches the vertical type motor, organism and the electrical machinery joined bodies coaxial structure, therefore calls continually the writing style colloid mill.

  • This product is equipped with the platoon to suppose keeps off the water plate, the operation use simply, installs the maintenance conveniently, the volume is small and so on the characteristic.

  • Grinds, the smashing, the emulsification, the mix, the disperser for the wet type ultramicron, isotropically, stirs the contour effect function.

  • Is suitable in each kind of liquid state shape medium material, the processing material sticks the density to be supposed to be smaller than 10,000 centipoise medium.

  • May defer to the customer to process nature special request and so on material different acidity, alkalinity, thick thickness has custom-made the production.
  • May replace and surpass the stone mill, the sand blast machine, the ball mill, the breast is uniform, stamp mill work and so on machine, mulser, three rollers machine.

Technical parameter a:

Main technical parameter

Degree of emulsification(um)

Change according to nature of the supplies
(T/h)

Mill Diameter
(mm)

Import diameter
(mm)

Export diameter
(mm)

Cooling circulation external diameter
(mm)

Main rotational speed
(r/min)

Power
(Kw)

External dimension
(LongWide High)mm

Weight
(Kg)

Type

JM-F500

2-50

10-50

Ø500

Ø150

Ø80

Ø12

1450-2900

45-200

14006501300

720

JM-F400

2-50

10-40

Ø400

Ø150

Ø80

Ø12

1450-2900

45-160

13006501300

680

JM-F350

2-50

6-35

Ø350

Ø125

Ø80

Ø12

1700-2900

37-45

12005501100

650

JM-F320

2-50

6-30

Ø320

Ø125

Ø80

Ø12

1700-2900

37

12005501100

650

JM-F320a

2-50

6-30

Ø320

Ø125

Ø80

Ø12

1700-2900

45

12005501100

840

JM-F250a

2-50

5-20

Ø250

Ø125

Ø60

Ø12

1700-2900

30

11005501050

472

JM-F250b

2-50

5-20

Ø250

Ø125

Ø60

Ø12

1700-3500

37

11005501050

510

JM-F200a

2-50

5-10

Ø200

Ø100

Ø50

Ø12

1700-3500

15

8204101050

350

JM-F200b

2-50

4-10

Ø200

Ø100

Ø50

Ø12

1700-3500

22

8204101000

415

JM-F200c

2-50

4-12

Ø200

Ø100

Ø50

Ø12

1700-3500

30

11005001000

455

JM-F180a

2-50

2-6

Ø180

Ø90

Ø40

Ø12

1700-3500

11

820450950

340

JM-F180b

2-50

2-6

Ø180

Ø90

Ø40

Ø12

1700-3500

15

820450950

360

JM-F180c

2-50

2-8

Ø180

Ø90

Ø40

Ø12

1700-3500

22

820500990

400

JM-F140a

2-50

1-4

Ø140

Ø66

Ø32

Ø12

1700-3500

7.5

810400930

280

JM-F140b

2-50

1-4

Ø140

Ø66

Ø32

Ø12

1700-3500

11

810410930

305

JM-F140c

2-50

1-4

Ø140

Ø66

Ø32

Ø12

1700-3500

15

810410930

350

JM-F130

2-50

0.7-3

Ø130

Ø65

Ø30

Ø12

1700-3500

5.5

810410930

280

JM-F120

2-50

0.7-2.5

Ø120

Ø65

Ø30

Ø12

1700-3500

5.5

810400930

275

JM-F100

2-50

0.5-2

Ø100

Ø65

Ø30

Ø12

1700-3500

5.5

800400920

270

JM-F80

2-50

0.5-1

Ø80

Ø47

Ø20

Ø12

1700-3500

4

700340810

105

JM-F65

2-50

0.2-0.5

Ø65

Ø47

Ø20

Ø8

1700-3500

2.2

720350780

90

JM-F60

2-50

0.02-0.1

Ø60

Ø47

Ø20

Ø8

1700-3500

1.5

650300700

60

Technical parameter b:

Main technical parameter

Degree of emulsification(um)

Change according to nature of the supplies
(T/h)

Mill Diameter
(mm)

Import diameter
(mm)

Export diameter
(mm)

Cooling circulation external diameter
(mm)

Main rotational speed
(r/min)

Power
(Kw)

External dimension
(LongWide High)mm

Weight
(Kg)

Type

JM-F500- 1

2-50

10-50

Ø500

Ø150

Ø80

Ø12

1450-2900

45-200

14006501300

720

JM-F400 -1

2-50

10-40

Ø400

Ø150

Ø80

Ø12

1450-2900

45-160

13006501300

680

JM-F350 -1

2-50

6-35

Ø350

Ø125

Ø80

Ø12

1700-2900

37-45

12005501100

650

JM-F320 -1

2-50

6-30

Ø320

Ø125

Ø80

Ø12

1700-2900

37

12005501100

650

JM-F320a -1

2-50

6-30

Ø320

Ø125

Ø80

Ø12

-17002900

45

11005501100

840

JM-F250a -1

2-50

5-20

Ø250

Ø125

Ø60

Ø12

1700-2900

30

11005501050

472

JM-F250b -1

2-50

5-20

Ø250

Ø125

Ø60

Ø12

1700-3500

37

11005501050

510

JM-F200a -1

2-50

5-10

Ø200

Ø100

Ø50

Ø12

1700-3500

15

8204101050

350

JM-F200b -1

2-50

4-10

Ø200

Ø100

Ø50

Ø12

1700-3500

22

8204101000

415

JM-F200c -1

2-50

4-12

Ø200

Ø100

Ø50

Ø12

1700-3500

30

11005001000

455

JM-F180a -1

2-50

2-6

Ø180

Ø90

Ø40

Ø12

1700-3500

11

820450950

340

JM-F180b -1

2-50

2-6

Ø180

Ø90

Ø40

Ø12

1700-3500

15

820450950

360

JM-F180c -1

2-50

2-8

Ø180

Ø90

Ø40

Ø12

1700-3500

22

820500990

400

JM-F140a -1

2-50

1-4

Ø140

Ø66

Ø32

Ø12

1700-3500

7.5

810400930

280

JM-F140b -1

2-50

1-4

Ø140

Ø66

Ø32

Ø12

1700-3500

11

810410930

305

JM-F140c -1

2-50

1-4

Ø140

Ø66

Ø32

Ø12

1700-3500

15

810410930

350

JM-F130 -1

2-50

0.7-3

Ø130

Ø65

Ø30

Ø12

1700-3500

5.5

810410930

280

JM-F120 -1

2-50

0.7-2.5

Ø120

Ø65

Ø30

Ø12

1700-3500

5.5

810400930

275

JM-F100 -1

2-50

0.5-2

Ø100

Ø65

Ø30

Ø12

1700-3500

5.5

800400920

270

JM-F80 -1

2-50

0.5-1

Ø80

Ø47

Ø20

Ø12

1700-3500

4

700340810

105

JM-F65 -1

2-50

0.2-0.5

Ø65

Ø47

Ø20

Ø8

1700-3500

2.2

720350780

90

JM-F60-1

2-50

0.02-0.1

Ø60

Ø47

Ø20

Ø8

1700-3500

1.5

650300700

60

Technical parameter c:

Main technical parameter

Degree of emulsification(um)

Change according to nature of the supplies
(T/h)

Mill Diameter
(mm)

Import diameter
(mm)

Export diameter
(mm)

Cooling circulation external diameter
(mm)

Main rotational speed
(r/min)

Power
(Kw)

External dimension
(LongWide High)mm

Weight
(Kg)

Type

JM-F500- 2

2-50

10-50

Ø500

Ø150

Ø80

Ø12

1450-2900

45-200

14006501300

720

JM-F400 -2

2-50

10-40

Ø400

Ø150

Ø80

Ø12

1450-2900

45-160

13006501300

680

JM-F350 -2

2-50

6-35

Ø350

Ø125

Ø80

Ø12

1700-2900

37-45

12005501100

650

JM-F320 -2

2-50

6-30

Ø320

Ø125

Ø80

Ø12

1700-2900

37

12005501100

650

JM-F320a -2

2-50

6-30

Ø320

Ø125

Ø80

Ø12

-17002900

45

12005501100

840

JM-F250a -2

2-50

5-20

Ø250

Ø125

Ø60

Ø12

1700-2900

30

11005501050

472

JM-F250b -2

2-50

5-20

Ø250

Ø125

Ø60

Ø12

1700-3500

37

11005501050

510

JM-F200a -2

2-50

5-10

Ø200

Ø100

Ø50

Ø12

1700-3500

15

8204101050

350

JM-F200b -2

2-50

4-10

Ø200

Ø100

Ø50

Ø12

1700-3500

22

8204101000

415

JM-F200c -2

2-50

4-12

Ø200

Ø100

Ø50

Ø12

1700-3500

30

11005001000

455

JM-F180a -2

2-50

2-6

Ø180

Ø90

Ø40

Ø12

1700-3500

11

820450950

340

JM-F180b -2

2-50

2-6

Ø180

Ø90

Ø40

Ø12

1700-3500

15

820450950

360

JM-F180c -2

2-50

2-8

Ø180

Ø90

Ø40

Ø12

1700-3500

22

820500990

400

JM-F140a -2

2-50

1-4

Ø140

Ø66

Ø32

Ø12

1700-3500

7.5

810400930

280

JM-F140b -2

2-50

1-4

Ø140

Ø66

Ø32

Ø12

1700-3500

11

810410930

305

JM-F140c -2

2-50

1-4

Ø140

Ø66

Ø32

Ø12

1700-3500

15

810410930

350

JM-F130 -2

2-50

0.7-3

Ø130

Ø65

Ø30

Ø12

1700-3500

5.5

810410930

280

JM-F120 -2

2-50

0.7-2.5

Ø120

Ø65

Ø30

Ø12

1700-3500

5.5

810400930

275

JM-F100 -2

2-50

0.5-2

Ø100

Ø65

Ø30

Ø12

1700-3500

5.5

800400920

270

JM-F80 -2

2-50

0.5-1

Ø80

Ø47

Ø20

Ø12

1700-3500

4

700340810

105

JM-F65 -2

2-50

0.2-0.5

Ø65

Ø47

Ø20

Ø8

1700-3500

2.2

720350780

90

JM-F60-2

2-50

0.02-0.1

Ø60

Ø47

Ø20

Ø8

1700-3500

1.5

650300700

60

Special precautions:

  • In the processing material does not allow to mix has the quartz sand, the glass fragments, the sweepings and so on the hard matter, strictly prohibits entering the colloid mill processing production.

  • It start, close it and can't start the machine before not washing, after the colloidal to rub there aren't organism , forbid dallying and reversing. Otherwise operate improper to can damage hard quality mechanical package or quiet mill , move mill or take place leakage burn electrical machinery ,etc. trouble seriously.

  • The product when does not affect the basic structure and the performance improvement, not separate informs even slightly. The product and the edition counterfeit must investigate (2,004 edition)
